Small Square Round Stainless Steel Tube Automatic CNC Hydraulic
Pipe Bending Machine
Mechanical features:
1. Economical automatic CNC computer control.
2. The feeding shaft and tilting shaft are driven by servo motor,
with high precision and good stability.
3. The elbow shaft adopts digital control full oil pressure, and
the auxiliary push adopts full oil pressure.
4. The electric control system is equipped with a fan for automatic
heat dissipation. If necessary, you can choose a numerical control
air conditioner to ensure the service life of the electric control
system.
5. The clamping nozzle can repeatedly enter the interference area
to perform the clamping function.
6. Support seat with anti wrinkle plate.
7. It has the function of programmable early core with drawal.
8. Suitable Materials: Square tube, Round tube and Rectangular tube,Carbon Steel pipe, stainless steel pipe, copper pipe, aluminum pipe
and others.
Main technical parameters:
| Machine type | SB-50CNC-2A-2S |
Maximum bending
R for carbon pipe is:1.5D | Ф50.8*2.0t |
Maximum bending
R for s.s pipe is
1.5D | Ф44.5*2.2t |
| Max Radius for bending | 250mm |
| Maximum feeding stroke | 2400mm |
Max angle for
bending | 190° |
Bending process
for every pipe | 16g roups |
| Working speed/bending speed | Max. 40 ° / S |
| Rotating pipe speed | Max. 270 ° / S |
| Feeding speed | Max. 900mm/ S |
| Accuracy bending angle | ±0.15 ° |
| Rotating angle accuracy | ±0.1 ° |
| Feeding length | ±0.1mm |
| Data input mode | working value ( Y.B.C) |
| Oil pressure | 14mpa |
| Rotor servo motor | 400W |
| Feeding servo motor | 1KW |
Main motor
power | 7.5kw |
| Weight | 2400kg |
Tube bending samples
